Copper Nickel Alloy Clad Plate Marine Corrosion Resistance
Marine environments are notoriously aggressive, demanding materials that offer both structural integrity and long-term corrosion resistance. DLX’s Copper-Nickel Clad Plate solves this by fusing pure nickel’s chemical stability with pure copper’s natural antifouling and high-conductivity properties. Designed for heat exchangers, desalination units, and ship-building components, our Ni-Cu bimetal plate eliminates the common weaknesses of traditional coatings.
- Overview
- Applications
- DLX Alloy
- FAQs
- Recommended Products
Product Overview of Copper Nickel Alloy Clad Plate
Our copper nickel alloy clad plate is a high-quality bimetallic composite with pure copper on one side and pure nickel on the other, metallurgically bonded for maximum integrity. This design delivers the best of both metals: the high electrical and thermal conductivity of pure copper combined with the exceptional corrosion resistance, especially in marine and seawater environments, of pure nickel.
Engineered for marine corrosion resistance, the nickel side provides reliable protection against seawater, chloride attack, and biofouling tendencies, while the copper side ensures efficient heat transfer and conductivity. The strong clad bond ensures long service life in shipbuilding, offshore platforms, desalination, heat exchangers, and other aggressive marine and industrial applications. Fully customizable in thickness ratio, overall dimensions, and surface finish.
Product Features of Copper Nickel Clad Plate Supplier
1.Ultimate Marine Protection: The pure nickel layer acts as a sacrificial and stable barrier against chloride-induced pitting and stress corrosion cracking.
2.Natural Antifouling Properties: The pure copper side releases ions that inhibit the growth of barnacles, algae, and other marine organisms, maintaining high efficiency in seawater cooling systems.
3.Atomic-Level Fusion: Our high-pressure rolling technology ensures the Ni and Cu layers are inseparable, even under the intense hydraulic pressure and mechanical vibrations found on offshore platforms.
4.High Conductive Efficiency: Boasting conductivity ≥85% IACS, it serves as an excellent electrical ground or power transition in maritime electronics.
5.Ductility for Marine Forming: The bimetal can be cold-formed into complex shapes (flanges, elbows, shells) without compromising the corrosion-resistant nickel interface.
Custom Attributes
| Attribute | Specification |
|---|---|
| Material Structure | Bimetal: Pure Nickel (Ni) Clad on Pure Copper (Cu) |
| Corrosion Resistance | Excellent in Seawater, Brine, and High-Humidity Marine Air |
| Trial MOQ | Starting from 10kg (Stock-dependent) |
| Sample Policy | Samples Available (Flexible Trial Order Support) |
| Nickel Layer (Ni) | ≥ 99.6% Purity (Corrosion Barrier) |
| Copper Layer (Cu) | ≥ 99.9% Purity (High Conductivity / Antifouling) |
| Bonding Strength | Metallurgical Fusion (No separation in marine vibrations) |
| Certifications | ISO 9001:2015, SGS, RoHS, Marine MTC available |
| Delivery Time | 3-5 days for samples; 15-25 days for trial batches |
Physical Properties & Chemical Composition
| Physical Properties | Pure Nickel Layer | Pure Copper Layer | Bimetal (Avg. at 20% Ni) |
|---|---|---|---|
| Density (g/cm³) | 8.89 | 8.96 | ~8.94 |
| Conductivity (% IACS) | ~22 | 100 - 101 | 82 - 88 |
| Thermal Conductivity (W/m·K) | 90.7 | 390 - 400 | ~330 |
| Elastic Modulus (GPa) | 207 | 110 - 128 | 135 - 150 |
| Material Layer | Ni (%) | Cu (%) | Fe (%) | C (%) | S (%) |
|---|---|---|---|---|---|
| Pure Nickel Side | 99.6 min | 0.10 max | 0.10 max | 0.05 max | 0.005 max |
| Pure Copper Side | - | 99.9 min | - | - | - |
Applications of Cu-Ni Clad Strip Factory
1.Shipbuilding: Corrosion-resistant liners for ballast tanks and salt-water cooling pipes.
2.Desalination Plants: Transition sheets and tube sheets for multi-stage flash (MSF) evaporation units.
3.Offshore Platforms: Protective cladding for splash-zone structural members and underwater housings.
4.Marine Electronics: Bimetallic heat sinks and grounding plates for radar and sonar systems.
5.Coastal Infrastructure: Fasteners and structural plates for tidal power systems and coastal bridges.
Key advantage：
✔Risk-Free Trial: Test our material performance with Samples tailored to your thickness requirements.
✔Low Entry Barrier: Unlike large mills, we support small-batch trial orders (10kg+) to aid your R&D process.
✔Direct Factory Price: Save up to 20% compared to international distributors by purchasing directly from our 12,000 m² Changzhou facility.
✔Full Data Transparency: Every trial batch comes with a detailed MTC covering bonding integrity and chemical purity.
⭐Company Intro - DLX Alloy
Changzhou DLX Alloy Co., Ltd. is not just a high-volume manufacturer; we are a specialized metallurgical partner for global marine engineering projects. We believe that innovation in the offshore sector begins with accessible material trials. Unlike large-scale mills that require multi-ton commitments, DLX has established a dedicated "Trial & Sample Unit" to support engineers and R&D departments in the North American and European maritime sectors. With a 12,000 m² facility and 20 years of focus on bimetallic bonding, we provide the industrial scale required for mass production while maintaining the flexibility of a boutique laboratory. At DLX, we lower the barrier to advanced material adoption, fostering a collaborative path toward safer and more durable marine infrastructure.
Quality & Standards : DLX implements a zero-defect quality system for battery materials. We utilize online ultrasonic testing to ensure 100% bond integrity and automated optical inspection (AOI) for surface defects. All materials are fully compliant with RoHS 3, REACH, and UL standards for electronic insulation and safety.
Forms: sheet, strips, or custom pre-cut tags.
Packaging: Vacuum-sealed anti-oxidation VCI bags inside reinforced wooden crates.
MOQ: 10kg for standard 2:8 ratio stock; 20kg for custom thickness or specific tempers.
Documentation: Full MTC (EN10204 3.1), RoHS compliance certificate, and Bond Strength Report.
FAQs:
Q1: What is the structure of this copper nickel alloy clad plate?
A: It is a bimetallic clad plate with one side pure copper and the other side pure nickel, metallurgically bonded. This combines copper’s high conductivity with nickel’s superior marine corrosion resistance.
Q2: Why is this clad plate suitable for marine corrosion resistance applications?
A: The pure nickel side offers excellent resistance to seawater corrosion, chloride pitting, and related marine attack, while the copper side provides conductivity and thermal performance. The bonded structure delivers long-term durability in offshore and shipbuilding environments.
Q3: Can the thickness ratio of copper to nickel be customized?
A: Yes. We offer fully customizable cladding ratios, overall plate thickness, width, length, and surface finishes to match the exact requirements of your marine or industrial project.
Q4: What are the main advantages over solid copper or solid nickel plates?
A: The copper nickel alloy clad plate provides the conductivity and cost benefits of copper on one side while delivering the marine corrosion resistance of nickel on the other, resulting in optimized performance and material efficiency.
